FEATURED PROJECT
View Layup Line InstallationSawmills
Debarker Replacement
Kelowna, BC
Hog System Relocation
Slocan, BC
BM&M Chip Screen
Kelowna, BC
Log Sort System
Elko, BC
Debarker Replacement
Year: 2007
Client: Tolko Industries Ltd.
Location: Kelowna, BC
Systematic was involved in the demolition of a small DLI canter line and the installation of the new Comact DDM6 small log line.
Project Highlights:
- Formed and placed the monolithic concrete foundation.
- Assembled mechanical, hydraulic, and pneumatic systems.
- Installation of Comact DDM6 debarker, wave feeder, speed-up conveyor, and two-way diversion transfer.
- Executed pre-shutdown activities.
- Supplied and erected structural steel frame.
- 3-month project completion with 5,400 man hours.
Other Services Provided:
- Design & Construction
- Heavy Rigging
- On-site Technical Services
- Project Management
- Sprinkler System Modifications
Hog System Relocation
Year: 2008
Client: Springer Creek Sawmill
Location: Slocan, BC
BM&M Chip Screen
Year: 2011
Client: Tolko Industries Ltd.
Location: Kelowna, BC
New chip screen, structural steel, and chuting for BM&M Chip Screen installation
Log Sort System
Year: 2022
Client: Canfor
Location: Elko, BC
Green field Installation of a Log sort system. This system enables a truck of logs to be autonomously sorted into size and species.
Project installation scope of work
- Excavation and ground preparation
- Underground utilities
- Concrete foundations
- Structural steel install including stairs and walkways
- Log decks
- Log singulation machine
- Log Conveyors
- Hog conveyors
- Scanner and scanner enclosure building
- Log kickers
- Concrete storage bunks
- MCC room and Operators building
- Washroom and septic system
- Fire protection piping
Plywood Plants
Layup Line Installation
Armstrong, BC
Lathe Line Relocation
Canoe, BC
Veneer Dryer Installation
Delta, BC
Plywood Plant Equipment Installation
Kamloops, BC
Dryer Rebuild
Quesnel, BC
Veneer Dryer Installation
Golden, BC
Dryer Installation
Armstrong, BC
Complete Peeler Plant
Christina Lake, BC
Press Foundations & Installation
Canoe, BC
Plywood Press Design and Installation
Kamloops, BC
Dryer Floor Replacement
Armstrong, BC
Veneer Dryer Installation
Delta, BC
Layup Line Installation
Year: 2007
Client: Tolko Industries Ltd.
Location: Armstrong, BC
Plywood Plant Venner Dryer and Stacker line
- Design
- Construction
- Project Management
Lathe Line Relocation
Year: 2014
Client: Canoe Forest Products
Location: Canoe, BC
Remove and refurbishment of decommissioned lathe and associated equipment from McBride, BC to be upgraded and reinstalled in Canoe, BC
- Installation of refurbished lathe infeed in new building addition.
- Refurbished pop-up conveyor
- New Ventech scanner
- New stacker
- New platform and walkways for maintenance access
Veneer Dryer Installation
Year: 2013
Client: Coastland Wood Industries LTD.
Location: Delta, BC
Completing the veneer dryer and stacker line rebuild and relocation at Coastland’s Annacis Island operations in Delta, BC.
Project Highlights:
- Installation of new dryer, including infeed/outfeed equipment
- Constructed associated walkways and platforms
Other Services Provided:
- Construction
- Design
Plywood Plant Equipment Installation
Year: 2006
Client: Thompson River Veneer Products Ltd.
Location: Kamloops, BC
Removed and replaced plywood plant equipment at the new greenfield building in Kamloops.
Project Highlights
- Installation of veneer dryer, hot press, hot oil system, and panel saw line.
- Created design for new press layout.
- Modified used press and associated in-feed and out-feed equipment
- 8-month project duration with 2,100 man hours
Services Provided
- Design
- Construction
Dryer Rebuild
Year: 2005
Client: West Fraser Timber Co. Ltd.
Location: Quesnel, BC
Completed rebuild of Westfraser’s plywood plant veneer dryer and other essential equipment.
Project Highlights:
- Installation of veneer dryer, hot press, hot oil system, and panel saw line.
- Created design for new press layout.
- Modified used press and associated in-feed and out-feed equipment
- 8-month project duration with 2,100 man hours
Other Services Provided:
- Design
- Construction
Veneer Dryer Installation
Year: 2005
Client: Louisiana-Pacific Canada Ltd.
Location: Golden, BC
Systematic was responsible for the installation of a new veneer dryer at Louisiana-Pacific’s Golden operations.
Project Highlights:
- Demolition of the two existing dryers.
- Installation of the new dryer foundation and drainage system.
- Installation of veneer dryer, veneer grade, and stacker line.
- Installation of steam coils, steam supply, and condensate return lines
Other Services Provided:
- Commissioning
- Construction
- Design
Dryer Installation
Year: 2005
Client: Tolko Industries Ltd.
Location: Armstrong, BC
Systematic completed a comprehensive Veneer Dryer Installation project, encompassing the installation of a state-of-the-art veneer dryer, a veneer grade, and a stacker line. Our experts meticulously commissioned the entire system, guaranteeing its seamless integration into Tolko’s Armstrong operations.
Project Highlights:
- Installation of veneer dryer, veneer grade, and stacker line
- Installation of steam coils, steam supply, and condensate return lines
Other Services Provided:
- Construction
- Commissioning
Complete Peeler Plant
Year: 2000
Client: Bell Pole Co. Ltd.
Location: Christina Lake, BC
Press Foundations & Installation
Year: 2002
Client: Federated Co-Op Ltd.
Location: Canoe, BC
Systematic designed the layout and foundations for a new plywood press, completing construction on a 15 ft deep press pit and sheet pile perimeter. Additionally the team installed the new press and its associated in-feed and out-feed equipment.
Project Highlights:
- Designed layout and foundations.
- Installed new plywood press and associated equipment.
- 1,144 hours of completed labour.
- 3-month project duration with 1144 labour hours.
Other Services Provided:
- Construction & Design
- Panel Sawline
- Layup Line
- Composers
- Hot Press
Plywood Press Design and Installation
Year: 2006
Client: Thompson River Veneer Products LTD.
Location: Kamloops, BC
Systematic was responsible for bringing new life to a used plywood press. This included redesigning the overall layout, applying alterations to the used press, and modifying the used in-feed/out-feed equipment and other associated elements. The final installation to ensure proper integration and functionality was also performed by our team.
Project Highlights:
- Designed the press layout.
- Modified used equipment.
- Installed press and associated elements.
- 6-month project duration with 2100 labour hours.
Other Services Provided:
- Hot Press Installation
- Hot Oil System Installation
- Panel Saw Line Installation
Dryer Floor Replacement
Year: 2017
Client: Tolko Industries LTD.
Location: Armstrong, BC
Veneer Dryer Installation
Year: 2018
Client: Coastland Wood Industries LTD.
Location: Delta, BC
Engineered Wood Plants
Debarker #1 Replacement
Swan Valley, Manitoba
LVL Lay-Up Line Prepress Extension
Golden, BC
Veneer Chipper Installation
Golden, BC
LVL Line
Golden, BC
LVL Beam Laminating Plant
Brisco, BC
Siding Conversion Project
Dawson Creek, BC
Press Rebuild
Debarker #2 & #3 Replacement
Swan Valley, MB / Dawson Creek, BC
Debarker #1 Replacement
Year: 2017
Client: Louisiana-Pacific Canada
Location: Swan Valley, Manitoba
An 11 day shutdown to replace an old A5 debarker with a new A8 debarker was executed.
Project Overview
Existing Debarker #2 Removal:
- Separate then remove barker ring and other auxiliary equipment
- Install temporary plates for clean-up conveyor
- Remove and modify platform/stairs for access to new Debarker
- Remove existing Debarker #2
- Package and store in equipment bone yard
Modify and Repair Debarker Support Structure:
- Clean and asses structural frame/components
- Modify and repair frame
- Install additional chute plating
- Replace ring pullout support column
New Debarker # 2 installation:
- Install new Debarker #2
- Install new barker ring
- Reinstall modified platform and stair assemblies
Debarker Auxiliary Equipment and Piping Installation:
- Modify infeed conveyor and install new centering roll
- Install new hydraulic power pack, lubricator and ring pullout HPU
- Install hydraulic control valve bank and associated piping
- Modify compressed air system and install newly supplied air receiver
LVL Lay-Up Line Prepress Extension
Year: 2006
Client: Louisiana-Pacific Canada Ltd.
Location: Golden, BC
Veneer Chipper Installation
Year: 2002
Client: Louisiana-Pacific Canada Ltd.
Location: Golden, BC
LVL Line
Year: 2000
Client: Evens Forest Products Ltd.
Location: Golden, BC
LVL Beam Laminating Plant
Year: 2003
Client: Brisco Wood Preservers Ltd.
Location: Brisco, BC
Siding Conversion Project
Year: 2018
Client: Louisiana-Pacific Canada LTD.
Location: Dawson Creek, BC
Provided demolition, structural erection and mechanical assembly services for the new siding manufacturing project.
Assembly of the following:
- Saw Line
- (2) Panel Saw Lines
- Hot press modifications
- Forming Line additions and modifications
- Fines (sawdust) processing and storage system
- Zinc Borite system
- MDI receiving, storage and delivery system
- Paint receiving, storage and delivery system
- Walkways, Platforms and Stairs
New Building and Process Piping Installation:
- Natural Gas Piping – To Manitoba safety standards
- Air Service Piping
- Process Water Piping
- MDI supply piping
- Wax supply piping
- Paint supply piping
Press Rebuild
Year: 2021
Client: Louisiana-Pacific Canada LTD.
Location:
An 11 day shutdown to replace an old A5 debarker with a new A8 debarker was executed.
Project Overview
Existing Debarker #2 Removal:
- Separate then remove barker ring and other auxiliary equipment
- Install temporary plates for clean-up conveyor
- Remove and modify platform/stairs for access to new Debarker
- Remove existing Debarker #2
- Package and store in equipment bone yard
Modify and Repair Debarker Support Structure:
- Clean and asses structural frame/components
- Modify and repair frame
Debarker #2 & #3 Replacement
Year: 2018
Client: Louisiana-Pacific Canada LTD.
Location: Swan Valley, MB / Dawson Creek, BC
Role in Provisions of Works and Services:
- Demolition and removal of existing A5 ring Debarkers
- Structural repairs of support structures
- New waste chuting as required
- Engineered lift plans
- Installation and assembly of new A8 Debarkers
Installation of all:
- Hydraulics
- Compressed Air
- Automatic Oilers
- Infeed and outfeed rolls and modifications
Field Commissioning and start up support
Services provided: Rigging, welding, millwrighting, iron working, field technical services - Modify and repair frame
Misc.
Pellet Plant Rebuild
Year: 2009
Client: Princeton Co-Gen Corp.
Location: Princeton, BC
Woodroom Upgrade
Year: 2008
Client: Zelstoff Celgar Pulpmill
Location: Castlegar, BC
Pellet & Shavings Plant
Year: 2006
Client: Westwood Fibre Products Ltd.
Location: Westbank, BC
Precipitators
Precipitator Rebuild
Armstrong, BC
Electrostatic Precipitator
Golden, BC
Wet Electrostatic Precipitator
Annacis Island, BC
Electrostatic Precipitator
Edmonton, AB
Powerhouse Dry Electrostatic Precipitators
Armstrong, BC
Precipitator Rebuild
Armstrong, BC
Precipitator Rebuild
Year: 2008
Client: Tolko Industries Ltd.
Location: Armstrong, BC
Electrostatic Precipitator
Year: 2006
Client: Louisiana-Pacific Canada Ltd.
Location: Golden, BC
Wet Electrostatic Precipitator
Year: 2011
Client: iLevel Weyerhaeuser
Location: Annacis Island, BC
Electrostatic Precipitator
Year: 2006
Client: Alberta Plywood
Location: Edmonton, AB
Powerhouse Dry Electrostatic Precipitators
Year: 2001
Client: Riverside Forest Products Ltd.
Location: Armstrong, BC
Precipitator Rebuild
Year: 2021
Client: Tolko Industries LTD.
Location: Armstrong, BC
Design, construction, and project management of a project for a plywood plant Electrostatic Precipitator
Energy Systems
Pellet Plant Gasifier Installation
Westbank, BC
Turbo Generator Installation
Kelowna, BC
Cooling Pond Replacment
Golden, B.C.
RTO
Canoe, BC
Pellet Plant Gasifier Installation
Year: 2005
Client: Westwood Fibre Products Ltd.
Location: Westbank, BC
Turbo Generator Installation
Year: 2000
Client: Riverside Forest Products Ltd.
Location: Kelowna, BC
14 MW Turbo Generator Installation:
- Removed turn-in and stator from existing plant in eureka California along with 24 MW turn-in and stator and cooling water tower for an installation at Tolko Armstrong
- Constructed building addition, piles, foundation, and structural steel
- Installation also included process piping, water cooling, and steam and condensate lines.
Cooling Pond Replacment
Year:
Client: Louisiana-Pacific Canada Ltd.
Location: Golden, B.C.
Existing Demolition
- Remove all existing 10inch branch pipe lines
- Remove two 70ft of the 24inch header pipe line
- Removal all timber support structure to elevation 8ft below pipes
- Remove all whirl-jet nozzles and refurbish
New Installation
- Install new steel support grid on existing timber columns
- Fabricate new junction boxes
- Install new spray clusters consisting of four 2inch branch lines, whirl jets, and junction box
- Fabricate and install six new 10inch branch lines
- Install two new 70ft sections of 24inch header line
RTO
Year: 2022
Client: Canoe Forest Products
Location: Canoe, BC
OSB & Siding
Super Screen Upgrade
Grande Prairie
Siding Conversion Project
Dawson Creek, BC
Siding Conversion Project
Swan Valley, MB
Shakeline Installation
Swan Valley, MB
Super Screen Upgrade
Year: 2022
Client: West Fraser Timber Co. LTD
Location: Grande Prairie
Completed all required modifications within a two day outage to allow for an upgrade of the fire supression of the main Super screen. Successfully replaced the legs and pannelling on the screen, as well as provided calibration and commissioning support.
Siding Conversion Project
Year: 2018
Client: Louisiana-Pacific Canada LTD.
Location: Dawson Creek, BC
Provided demolition, structural erection and mechanical assembly services for the new siding manufacturing project.
Assembly of the following:
- Saw Line
- (2) Panel Saw Lines
- Hot press modifications
- Forming Line additions and modifications
- Fines (sawdust) processing and storage system
- Zinc Borite system
- MDI receiving, storage and delivery system
- Paint receiving, storage and delivery system
- Walkways, Platforms and Stairs
New Building and Process Piping Installation:
- Natural Gas Piping – To Manitoba safety standards
- Air Service Piping
- Process Water Piping
- MDI supply piping
- Wax supply piping
- Paint supply piping
Siding Conversion Project
Year: 2021
Client: Louisiana-Pacific Canada LTD.
Location: Swan Valley, MB
Shakeline Installation
Year: 2021
Client: Louisiana-Pacific Canada LTD.
Location: Swan Valley, MB
Our Work Speaks for Itself
Systematic’s industrial construction projects range from the installation of complete plants and processing lines to the installation of single machines.
